Company Advantages

· The production process of LEMAX energy storage battery has been greatly improved by our professionals. They carry out a complete management system to conduct the production of the product.

· Equipped with advanced facilities, we focus more on the quality assurance.

· Through several years of operation, Shenzhen LEMAX New Energy Co.,Ltd has formed mature management system.

海报 (9)

 Product parameters

Items Parameters Remarks
Manufacturer EVE /
Model No. LF280K /
Nominal Capacity 280Ah 0.5C, 25±2℃, 2.5-3.65V
Nominal Voltage 3.2V 0.5C, 2.5~3.65V
Rated Energy 896Wh 0.5C, 25±2℃, 2.5-3.65V
Initial IR ≤0.25 mΩ AC, 1kHz, 40%SOC
Charging Cut-off Voltage 3.65V /
Discharging Cut-off Voltage 2.5V (T>0℃) /
2.0V (T≤0℃)
Standard Charging Current 140A 0.5C
Standard Discharging Current 140A 0.5C
Cycling Performance25℃ Standard Cycle 6000 Cycles Applying 300kgf±20kgf pre-pressure, 0.5C,2.5~3.65V, Capacity retention rate≥80%, Orfollow the cycling method provided by EVE
Cycling Performance45℃ Standard Cycle 2500 Cycles Applying 300kgf±20kgf pre-pressure, 0.5C,2.5~3.65V, Capacity retention rate≥80%, Orfollow the cycling method provided by EVE
Operation TemperatureCharging Temperature 0~60℃ /
Operation TemperatureDischarging Temperature -30~60℃ /
Storage Temperature 1 year 0~35℃ Delivery SOC State
Storage Temperature 3 months 0~35℃ Delivery SOC State
Storage Temperature 1 month -20~45℃ Delivery SOC State
Battery Dimension 207.2*72*173.7mm /
Battery Weight 5420g±300 g /
Certification UL, MSDS, UN38.3, CE,CCS,REACH /

Long-Term Storage

After the battery is charged, it should be used as soon as possible to avoid loss of usable capacity due to self-discharge. If storage is required, the battery needs to be stored in a low SOC state. The recommended storage conditions are 30%~40%SOC 0~25℃ ≤60%RH.

Transportation

Battery for shipping should be packed in boxes with the SOC of 30%~40%. The severe vibration, impact, extrusion, sun and rain should be prevented during shipping. Applicable methods of transportation include truck, train, ship, airplane, etc.

Operation Precautions

•  It is forbidden to inversely charge. Correctly connect the positive and negative poles of the battery, and reverse charging is strictly prohibited.

• It is forbidden to over-discharge. During the normal use of the battery, in order to prevent over-discharge, the battery should be charged regularly to maintain the voltage above 2.8 V

• It is strictly forbidden to immerse the battery in water. When it is not in use, it should be placed in a cool and dry environment.

• It is forbidden to use and leave the battery next to heat and high temperature sources, such as fire, heater, etc.

• Please use a special charger for lithium-ion batteries when charging.

• During usage, it is strictly prohibited to reverse the positive and negative terminals of the battery.

• Do not throw the battery in the fire or heater.

• It is forbidden to use metal to directly connect the positive and negative terminals of the battery to short-circuit.

• It is forbidden to transport or store the battery with metal, such as hairpins, necklaces, etc.

• It is forbidden to knock or throw, step on, or bend the battery.

• It is forbidden to directly solder the battery.

• It is forbidden to directly pierce the battery with nails or other sharp objects.

• It is forbidden to use or place the battery under high temperature (under hot sunlight), such as in a car under direct sunlight or in a hot day.

• It is forbidden to use it in places with strong static electricity and strong magnetic fields.

• If the battery leaks and the electrolyte splashes on the skin, clothes, eyes, mouth, nose, etc., immediately wash the affected area with running water and send to a doctor for treatment immediately, otherwise it will cause serious harm to the human body.

•  If the battery emits peculiar smell, heat, discoloration, deformation, or any abnormality during use, storage, or charging, immediately remove the battery from the device or charger and stop using it.

DIMENSION

尺寸 (2)


Company Features

· LEMAX is known for the stable and reliable quality of energy storage battery.

· Shenzhen LEMAX New Energy Co.,Ltd owns acres of production parks. Shenzhen LEMAX New Energy Co.,Ltd has set a production base and a marketing center. Shenzhen LEMAX New Energy Co.,Ltd can guarantee the sufficient supply of energy storage battery with our acres of production parks.

· Each of the details of energy storage battery is emphasized by Shenzhen LEMAX New Energy Co.,Ltd for higher quality. Contact!


Enterprise Advantages

Our company has extensively taken excellent talents in, and we established a highly educated management team of high quality and efficiency. Based on the modern management concept, our management staff are committed to leading our company to develop faster and better.

We take the quantitative business and personalized service as the standard, and consider the needs of customers as the guide to provide consumers with intimate services.

Our company always adheres to the corporate mission of 'leading the development of the industry and promoting social progress', and we adhere to the business philosophy of 'honesty-based and law-abiding, customer first, mutual benefit and win-win'. We sincerely provide customers with quality products and services. Moreover, we are committed to becoming an industrial model enterprise with industry influence and driving force.

Founded in LEMAX has been working on the production and sales of And our production level is better within the industry.

Through continuous improvement of sales channels, our company has established an unobstructed market channel and sales network at home and abroad with our major distribution outlets. It expands the visibility of our products.
