Product details of the rack mount lithium battery
Quick Detail
LEMAX rack mount lithium battery is designed by a team of experienced experts using the latest design concept based on a strict design process. As time goes by, the quality and performance of the product are still good as before. What is crucial to Shenzhen LEMAX New Energy Co.,Ltd is the quality of rack mount lithium battery.
Product Information
Our rack mount lithium battery has the following advantages over peer products.
![Stackable Lithium Battery]()
Parameters
| Model |
LM-JS-51.2V100Ah |
| Battery Type |
LiFePO4 |
| Capacity |
100Ah |
| Rated Voltage |
51.2V |
| Total Energy |
5.12kWh |
| Working Voltage Range |
40 ~58.4V |
| Max Charge Current |
100A |
| Max Discharge Current |
100A |
| Standard Charge Current |
50A |
| Standard Discharge Current |
100A |
| DOD |
1 |
| Max Parallel Quantity |
15 |
| Designed Life-span |
8000 cycles
(Test conditions:100%DOD,0.2C charge&discharge at +25 ℃) |
| Operating Temperature |
Charge :0℃~60℃
Discharge :-10℃~60℃ |
| Operation Humidity |
5~95% |
| Nominal Operation Altitude |
<3000m |
| IP protection |
IP54 |
| Installation Method |
Stacking installation |
| Communication |
RS232, RS485, CAN |
| Certification |
MSDS、UN38.3、CE、ISO |
| Net Weight(Kg) |
46.3 |
| Gross Weight (Kg) |
48 |
| Production Dimension (mm) |
635*400*192 |
| Carton Dimension (mm) |
700*465*240 |
| *The actual size and weight are subjected to the physical product. |
Application Scenarios
![Application Scenarios]()
![Brand Inverter]()
Packing Information
| Carton Size |
700*465*240mm |
| Carton packing weight |
48KG |
Project Cases
![Project Cases]()
Company Introduction
Shenzhen LEMAX New Energy Co.,Ltd has gained high popularity and recognition for its rack mount lithium battery. As the main force in rack mount lithium battery industry, LEMAX put relentless efforts into designing and manufacturing products. It is believed that LEMAX will grow into the world's number one rack mount lithium battery brand. Inquire online!
Our products are reliable in quality, various in type and affordable in price. Customers in need are welcomed to contact us. We sincerely hope to reach friendly cooperation, common development and mutual benefit with you!
