Product details of the power inverter
Product Information
The materials of LEMAX power inverter meet the international quality standards. Through the use of advanced testing equipment in products, many quality problems can be found in time, thus effectively improving the quality of products. In tune with the track of market development, the product is widely accepted by customers.
Parameters
| Model |
LMS6KHX-BP |
| Rated Power |
6KVA / 6KW |
| System DC Voltage |
48Vdc |
| Parallel Option |
Yes, up to 6 units |
| Monitoring Option |
WiFi / GPRS |
| Inverter Output |
| AC Output |
220V-230V-240VAC |
| Surge Power |
12000VA |
| Peak Conversion Efficiency |
94% |
| Transfer Time |
10ms (for persional computers)
20ms (for home appliances) |
| Waveform |
Pure sine wave |
| Self Consumption at 0 Load |
<70 watt |
| Solar Charger |
| Type of PV Array Input Terminal |
MC4 |
| Max.PV Array Open Circuit Voltage |
500Voc |
| Max.PV Input Current / Per String |
16A |
| Number of PV Array Input |
2 Strings |
| Max.PV Array Power |
Each String: 4000 watt； Total 8000 watt |
| MPPT Working Range |
120-450VDC |
| Battery Overcharge Protection |
60VDC |
| Max Solar Charge Current |
100A |
| AC Charger (Grid / Generator) |
| Max.Grid Charge Current |
80A |
| Max.(AC+PV) Charge Current |
100A |
| Protection |
Overload, Short circuit, Overcurrent, Overvoltage, Undervoltage, Over-Frequency, Under-Frequency, Overheat, Lighning, Surge Power |
| Physical |
| Dimension |
460x395x132mm |
| Net Weight |
13.5kg |
| Communication Interface |
CAN / RS485 / USB |
| Environment |
| Humidity |
5% to 95% Relative Humidity (non-condensing) |
| Altitude |
<2000m |
| Operating Temperature |
0°C~55°C |
| Storage Temperature |
-15°C~60°C |
| Noise |
<60db |
| Certificate |
CE, IEC62109-1, IEC62109-2 |
