Product details of the inverter for sale
Product Introduction
LEMAX inverter for sale is designed to gain long-lasting popularity. The quality testing unit is built under strict quality control parameters. The high cost performance makes the product have a broad market prospect in the industry.
Parameters
| Model |
LMS6KHX-BP |
| Rated Power |
6KVA / 6KW |
| System DC Voltage |
48Vdc |
| Parallel Option |
Yes, up to 6 units |
| Monitoring Option |
WiFi / GPRS |
| Inverter Output |
| AC Output |
220V-230V-240VAC |
| Surge Power |
12000VA |
| Peak Conversion Efficiency |
94% |
| Transfer Time |
10ms (for persional computers)
20ms (for home appliances) |
| Waveform |
Pure sine wave |
| Self Consumption at 0 Load |
<70 watt |
| Solar Charger |
| Type of PV Array Input Terminal |
MC4 |
| Max.PV Array Open Circuit Voltage |
500Voc |
| Max.PV Input Current / Per String |
16A |
| Number of PV Array Input |
2 Strings |
| Max.PV Array Power |
Each String: 4000 watt； Total 8000 watt |
| MPPT Working Range |
120-450VDC |
| Battery Overcharge Protection |
60VDC |
| Max Solar Charge Current |
100A |
| AC Charger (Grid / Generator) |
| Max.Grid Charge Current |
80A |
| Max.(AC+PV) Charge Current |
100A |
| Protection |
Overload, Short circuit, Overcurrent, Overvoltage, Undervoltage, Over-Frequency, Under-Frequency, Overheat, Lighning, Surge Power |
| Physical |
| Dimension |
460x395x132mm |
| Net Weight |
13.5kg |
| Communication Interface |
CAN / RS485 / USB |
| Environment |
| Humidity |
5% to 95% Relative Humidity (non-condensing) |
| Altitude |
<2000m |
| Operating Temperature |
0°C~55°C |
| Storage Temperature |
-15°C~60°C |
| Noise |
<60db |
| Certificate |
CE, IEC62109-1, IEC62109-2 |
![inverter]()
Company Feature
• Our company has great traffic conditions, and multi traffic lines pass our company's location. It is beneficial to the outward shipping of products.
• Established in LEMAX becomes the leading enterprise in the industry after years of practice and exploration.
• The products we manufacture are very popular among customers. They are not only sold well in major provinces and cities in China, but also exported to different countries and regions overseas.
• LEMAX adheres to the service concept to be sincere, devoted, considerate and reliable. We are dedicated to providing customers with comprehensive and quality services to meet the different needs of customers. We look forward to building win-win partnerships.
LEMAX produces high-quality Why not leave your contact information? We promise to provide satisfactory products for you.
