 Product parameters

Items Parameters Remarks
Manufacturer EVE /
Model No. LF100LA /
Nominal Capacity 100Ah 0.2C, 25℃±2℃, 2.5-3.65V
Nominal Voltage 3.2V 0.2C, 25℃±2℃, 2.5-3.65V
Rated Energy 320Wh 0.2C, 25℃±2℃, 2.5-3.65V
ACR ≤0.5mΩ AC, 1kHz, 25%SOC
Charging Cut-off Voltage 3.65V /
Discharging Cut-off Voltage 2.5 (0℃ /
StandardCharging/DischargingCurrent 0.2C/0.2C 25℃±2℃
Maximum charging current 1C 25℃±2℃
Cycling Performance25℃ Standard Cycle 5000 Cycles0.5C/0.5C Capacity Retention≥80%
Cycling Performance35℃ Standard Cycle 3500 Cycles0.5C/0.5C Capacity Retention≥80%
Cycling Performance45℃ Standard Cycle 2000 Cycles0.5C/0.5C Capacity Retention≥80%
Operation TemperatureCharging Temperature 0~65℃ /
Operation TemperatureDischarging Temperature -20~65℃ /
Storage Temperature >1 month 0~35℃ Delivery SOC State (20~40%)
Storage Temperature ≤1 month -20~45℃ Delivery SOC State (20~40%)
Battery Dimension 160*50*118.5mm /
Battery Weight 1985±100 g /
Certification UL, MSDS, UN38.3, CE,REACH /

Long-Term Storage

After the battery is charged, it should be used as soon as possible to avoid loss of usable capacity due to self-discharge. If storage is required, the battery needs to be stored in a low SOC state. The recommended storage conditions are: 20%~40% SOC, 0℃~35℃, relative humidity ≤60%.

Transportation

Battery for shipping should be packed in boxes with the SOC of 20%~40%. The severe vibration, impact, extrusion, sun and rain should be prevented during shipping. Applicable methods of transportation include truck, train, ship, airplane, etc.

Operation Precautions

• It is strictly forbidden to immerse the battery in water. When it is not in use, it should be placed in a cool and dry environment.

• It is forbidden to use and leave the battery next to heat and high temperature sources, such as fire, heater, etc.

• Please use a special charger for lithium-ion batteries when charging.

• During usage, it is strictly prohibited to reverse the positive and negative terminals of the battery.

• Do not throw the battery in the fire or heater.

• It is forbidden to use metal to directly connect the positive and negative terminals of the battery to short-circuit.

• It is forbidden to transport or store the battery with metal, such as hairpins, necklaces, etc.

• It is forbidden to knock or throw, step on, or bend the battery.

• It is forbidden to directly weld the battery or pierce the battery with nails or other sharp objects.

• It is forbidden to use or place the battery under high temperature (under hot sunlight), otherwise it may cause the battery to overheat or fail to function and shorten its life.

• It is forbidden to use it in places with strong static electricity and strong magnetic fields; otherwise it will easily damage the battery safety protection device and bring hidden dangers of safety.

• If the battery leaks and the electrolyte splashes on the skin or clothes, immediately wash the affected area with running water. If the battery leaks and the electrolyte enters the open parts of the human body such as the eyes, mouth, nose, etc., immediately rinse the eyes with a large amount of water and send to a doctor for treatment immediately, otherwise it will cause serious harm to the human body.

•  If the battery emits peculiar smell, heat, discoloration, deformation, or any abnormality during use, storage, or charging, immediately remove the battery from the device or charger and stop using it.

Dimension

尺寸


Company Advantages

· This uniquely designed LEMAX lifepo4 battery manufacturer comes from our innovative designers.

· Owning to our new advanced technology, Our lifepo4 battery manufacturer is in higher performance.

· Without consideration of the LEMAX staff, lifepo4 battery manufacturer can not be produced to be so excellent.


Company Features

· Shenzhen LEMAX New Energy Co.,Ltd has gained several patents for its technology applied in production of lifepo4 battery manufacturer.

· Shenzhen LEMAX New Energy Co.,Ltd actively implements the ISO 14001 Environmental Management System.

· With our progress in managing energy, water, and waste, we continue to find ways to reduce the company's impact on the environment and embed sustainability throughout our businesses.


Application of the Product

LEMAX's lifepo4 battery manufacturer has been widely used in many industries.

Guided by the actual needs of customers, LEMAX provides customers with comprehensive, perfect and high-quality solutions based on the interests of customers.
