Parameters
| Items | Parameters | Remarks |
| Manufacturer | EVE | / |
| Model No. | LF280K | / |
| Nominal Capacity | 280Ah | 0.5C, 25±2℃, 2.5-3.65V |
| Nominal Voltage | 3.2V | 0.5C, 2.5~3.65V |
| Rated Energy | 896Wh | 0.5C, 25±2℃, 2.5-3.65V |
| Initial IR | ≤0.25 mΩ | AC, 1kHz, 40%SOC |
| Charging Cut-off Voltage | 3.65V | / |
| Discharging Cut-off Voltage | 2.5V (T>0℃) 2.0V (T≤0℃) | / |
| Standard Charging Current | 140A | 0.5C |
| Standard Discharging Current | 140A | 0.5C |
| Cycling Performance 25℃ Standard Cycle | 6000 Cycles | Applying 300kgf±20kgf pre-pressure, 0.5C, 2.5~3.65V, Capacity retention rate≥80%, Or follow the cycling method provided by EVE |
| Cycling Performance 45℃ Standard Cycle | 2500 Cycles | Applying 300kgf±20kgf pre-pressure, 0.5C, 2.5~3.65V, Capacity retention rate≥80%, Or follow the cycling method provided by EVE |
| Operation Temperature Charging Temperature | 0~60℃ | / |
| Operation Temperature Discharging Temperature | -30~60℃ | / |
| Storage Temperature 1 year | 0~35℃ | Delivery SOC State |
| Storage Temperature 3 months | 0~35℃ | Delivery SOC State |
| Storage Temperature 1 month | -20~45℃ | Delivery SOC State |
| Battery Dimension | 207.2*72*173.7mm | / |
| Battery Weight | 5420g±300 g | / |
| Certification | UL, MSDS, UN38.3, CE,CCS,REACH | / |
Long-term Storage
After the battery is charged, it should be used as soon as possible to avoid loss of usable capacity due to self-discharge. If storage is required, the battery needs to be stored in a low SOC state. The recommended storage conditions are 30%~40%SOC 0~25℃ ≤60%RH.
Transportation
Battery for shipping should be packed in boxes with the SOC of 30%~40%. The severe vibration, impact, extrusion, sun and rain should be prevented during shipping. Applicable methods of transportation include truck, train, ship, airplane, etc.
Operation Precautions
• It is forbidden to inversely charge. Correctly connect the positive and negative poles of the battery, and reverse charging is strictly prohibited.
• It is forbidden to over-discharge. During the normal use of the battery, in order to prevent over-discharge, the battery should be charged regularly to maintain the voltage above 2.8 V
• It is strictly forbidden to immerse the battery in water. When it is not in use, it should be placed in a cool and dry environment.
• It is forbidden to use and leave the battery next to heat and high temperature sources, such as fire, heater, etc.
• Please use a special charger for lithium-ion batteries when charging.
• During usage, it is strictly prohibited to reverse the positive and negative terminals of the battery.
• Do not throw the battery in the fire or heater.
• It is forbidden to use metal to directly connect the positive and negative terminals of the battery to short-circuit.
• It is forbidden to transport or store the battery with metal, such as hairpins, necklaces, etc.
• It is forbidden to knock or throw, step on, or bend the battery.
• It is forbidden to directly solder the battery.
• It is forbidden to directly pierce the battery with nails or other sharp objects.
• It is forbidden to use or place the battery under high temperature (under hot sunlight), such as in a car under direct sunlight or in a hot day.
• It is forbidden to use it in places with strong static electricity and strong magnetic fields.
• If the battery leaks and the electrolyte splashes on the skin, clothes, eyes, mouth, nose, etc., immediately wash the affected area with running water and send to a doctor for treatment immediately, otherwise it will cause serious harm to the human body.
• If the battery emits peculiar smell, heat, discoloration, deformation, or any abnormality during use, storage, or charging, immediately remove the battery from the device or charger and stop using it.
Dimension
