Product details of the ev charger
Quick Overview
LEMAX ev charger is specifically designed according to demand of our customers. The product has many competitive edges, such as strong durability, high cost-performance, and so on. This product will be approved by more customers with a good reputation.
Product Information
Next, LEMAX will show you ev charger's details.
Parameters
|
Model |
LM-DC030K-EU |
| Input |
Power Supply |
3P+N+PE |
| Rated Voltage |
400V AC |
| Rated Current |
45A |
| Frequency |
50/60Hz |
| Output |
Output Voltage |
150V~1000V DC |
| Maximum Current |
75A |
| Rated Power |
30kW |
| User Interface |
Charge Connector |
CCS2 |
| Cable Length |
5m |
| Enclosure |
Galvanized steel |
| LED Indicator |
Green/Red/Yellow |
| I CD Display |
4.3’color touch screen |
| RFID Reader |
Mifare ISO/IEC14443 A |
| Start Mode |
RFID card/App/Plug&Play |
| Communication |
WiFi |
Yes |
| Ethernet |
Yes |
| 4G |
Optional |
| Bluetooth |
No |
| OCPP |
OCPP1.6 Json (OCPP 2.0 upgradable) |
| Safety |
RCD |
Type A |
| Meter |
Yes |
| Emergency Stop |
Yes |
| Ingress Protection |
IP54 |
| Impact Protection |
IK08 |
| Electrical Protection |
Over current protection, Residual current protection, Surge protection, Over/Under voltage protection, Over/Under frequency protection, Over temperature protection |
| Certification |
CE/CB |
| Certification Standard |
ENIEC 61851-1:2019, IEC61851-1:2017, EN61851-23:2014, EN61851-24:2014 |
| Warranty |
2 years |
| Environment |
Installation |
Wall-mount/Pole-mount(Optional) |
| Cooling Method |
Fan cooling |
| Noise |
≤60dB |
| Work Temperature |
-30℃~+50℃ |
| Work Humidity |
5%~95% |
| Work Altitude |
<2000m |
| Package |
Product Dimension |
707*560*217mm(W*D*H) |
| Package Dimension |
847*762*420mm(W*D*H) |
| Net Weight |
35.3kg |
| Gross Weight |
40kg |
| External Package |
Carton |
