Parameters
| Items | Parameters | Remarks |
| Manufacturer | EVE | / |
| Model No. | LF100LA | / |
| Nominal Capacity | 100Ah | 0.2C, 25℃±2℃, 2.5-3.65V |
| Nominal Voltage | 3.2V | 0.2C, 25℃±2℃, 2.5-3.65V |
| Rated Energy | 320Wh | 0.2C, 25℃±2℃, 2.5-3.65V |
| ACR | ≤0.5mΩ | AC, 1kHz, 25%SOC |
| Charging Cut-off Voltage | 3.65V | / |
| Discharging Cut-off Voltage | 2.5 (0℃| / |
|
| Standard Charging/Discharging Current | 0.2C/0.2C | 25℃±2℃ |
| Maximum charging current | 1C | 25℃±2℃ |
| Cycling Performance 25℃ Standard Cycle | 5000 Cycles 0.5C/0.5C | Capacity Retention≥80% |
| Cycling Performance 35℃ Standard Cycle | 3500 Cycles 0.5C/0.5C | Capacity Retention≥80% |
| Cycling Performance 45℃ Standard Cycle | 2000 Cycles 0.5C/0.5C | Capacity Retention≥80% |
| Operation Temperature Charging Temperature | 0~65℃ | / |
| Operation Temperature Discharging Temperature | -20~65℃ | / |
| Storage Temperature >1 month | 0~35℃ | Delivery SOC State (20~40%) |
| Storage Temperature ≤1 month | -20~45℃ | Delivery SOC State (20~40%) |
| Battery Dimension | 160*50*118.5mm | / |
| Battery Weight | 1985±100 g | / |
| Certification | UL, MSDS, UN38.3, CE,REACH | / |
Long-term Storage
After the battery is charged, it should be used as soon as possible to avoid loss of usable capacity due to self-discharge. If storage is required, the battery needs to be stored in a low SOC state. The recommended storage conditions are: 20%~40% SOC, 0℃~35℃, relative humidity ≤60%.
Transportation
Battery for shipping should be packed in boxes with the SOC of 20%~40%. The severe vibration, impact, extrusion, sun and rain should be prevented during shipping. Applicable methods of transportation include truck, train, ship, airplane, etc.
Operation Precautions
• It is strictly forbidden to immerse the battery in water. When it is not in use, it should be placed in a cool and dry environment.
• It is forbidden to use and leave the battery next to heat and high temperature sources, such as fire, heater, etc.
• Please use a special charger for lithium-ion batteries when charging.
• During usage, it is strictly prohibited to reverse the positive and negative terminals of the battery.
• Do not throw the battery in the fire or heater.
• It is forbidden to use metal to directly connect the positive and negative terminals of the battery to short-circuit.
• It is forbidden to transport or store the battery with metal, such as hairpins, necklaces, etc.
• It is forbidden to knock or throw, step on, or bend the battery.
• It is forbidden to directly weld the battery or pierce the battery with nails or other sharp objects.
• It is forbidden to use or place the battery under high temperature (under hot sunlight), otherwise it may cause the battery to overheat or fail to function and shorten its life.
• It is forbidden to use it in places with strong static electricity and strong magnetic fields; otherwise it will easily damage the battery safety protection device and bring hidden dangers of safety.
• If the battery leaks and the electrolyte splashes on the skin or clothes, immediately wash the affected area with running water. If the battery leaks and the electrolyte enters the open parts of the human body such as the eyes, mouth, nose, etc., immediately rinse the eyes with a large amount of water and send to a doctor for treatment immediately, otherwise it will cause serious harm to the human body.
• If the battery emits peculiar smell, heat, discoloration, deformation, or any abnormality during use, storage, or charging, immediately remove the battery from the device or charger and stop using it.
Dimension
